GSIMT GIGABIT SWITCH INTERFACE MODULE

The GSIMT is a Managed Layer 2/3 Gigabit LAN Switch that supports the data network by providing  12 10/100/1000 Base-T interface ports. As a router, the GSIMT will support path management and queuing functions of data packets for external WAN and internal LAN networks.

Only two GSIMT per cabinet may be installed for a system total of 6 in the OfficeServ 7400 system. The GSIMTmay be installed in any universal slot.

•      12 10/100/1000 Base-TX ports RJ-45

•      L3 Unicasting Protocol

•      L3 Multicasting Protocol

•      Ethernet Switch 802.3 compatible

•      Packet Priority Control 802.1p

•      VLAN Networking 802.1q

•      Spanning Tree Protocol RSTP, PVST+

•      Diffserv

•      Flow Control 802.3x

•       Multi-casting IGMPv1/v2, DVMRP, PIM-SM
