GPLIMT (GIGABIT PoE LAN INTERFACE MODULE)

The GPLIMT functions as a Layer 2 LAN switch capable of operating in the gigabit range. It sends/receives data from the internal LAN providing (12) 10/100/1000 Base-T auto sensing full/half duplex LAN ports. The GPLIMT supports Power over Ethernet (PoE) compliant to IEEE 802.af and can power any compliant device through any of its Ethernet ports. The GPLIMT is a Managed Switch and offers many advanced features for network security and QoS. The GPLIMT may be installed in any universal slot of the 7400 cabinet with no maximum on the number that may be provisioned in the system.

•      (12) 10/100 BaseT auto sensing full/half duplex LAN ports (RJ-45)

•      (2) 10/100/1000 BaseTX auto sensing full/half duplex LAN ports

•      PoE to provide power to all IEEE 802.af compliant devices including Samsung ITP Phones and SMT-R2000

WAPs

•      L2 Switching - Managed

•       VLAN functions (802.1q)

•      QoS (802.1p)

•      Multi-Casting (IGMP Snooping)

•      Spanning Tree Protocol
