GWIMT (GIGABIT WAN INTERFACE MODULE)

The GWIMT functions as a Layer 3 Router which transmits/receives data to and from the external network. It provides (3) 10/100/1000 Base-T interfaces which may be configured as LAN or WAN to connect to Internal or External networks. It also has a V.35 serial port for connection to customer provided CSU/DSU requiring a cable which must be ordered separately as well as an HSSI port for T3 connections. Only one GWIMT per cabinet may be installed for a system total of 3 in the OfficeServ 7400 system. The GWIMT may be installed in any universal slot.

•      (3) 10/100/1000 BaseT interfaces (RJ-45)

•       V.35 Serial port for  T1 interface

•      HSSI port for T3 connections

•      Routing Functions: Static Routing, Dynamic Routing (RIP, OSPF), Inter VLAN routing, Multicast IGMP

•      Network Functions: NAT/NAPT, Firewall, IDS, VPN, QoS
